MAESTRO THEREMIN

Ref Designator Description
CR1,CR2,CR5,CR6 Diode,1N4151, 1N4158 Substitute
CR3A thru CR3D Diode,1N4004
CR4 Diode,Zener,1N5356A
IC1 IC, MFC6040, MFC3340 Substitute
Q1,Q2,Q4-7 Transistor, MPS6514, 2N3904 Substitute
Q3 Transistor, MPS6518, 2n3906 Substitute
    Unless otherwise specified:
    • All Resistors in Ohms, +/-10%, 1/2W.
    • All Capacitors in Mfd.
